2006 Yamaha ATV & Quad Bike Specs

Engine Spec

Engine Detail: 421cc, 4-Stroke Single, Liquid Cooled w/ Fan, SOHC

Engine Capacity (cc / Ci ): 421 cc / 25.7

Engine Valves: SOHC

Valve Configuration: 2-valves

Total Valves: 2

Engine Type: 4-Stroke

Engine Cooling: Liquid Cooled w/ Fan

Engine Cylinders: Single

Engine Braking: Front & Rear Wheel

Displacement To Weight CC: 0.82

Bore Stroke(mm): 84.5 mm x 75 mm

Bore Stroke(in): 3.33in. x 2.96 in.

Compression Ratio: 10:1

Fuel System: Mikuni 33mm BSR

Fuel System Brand: Mikuni

Carburetor Size MM: 33

Carborator Count: 1

Fuel Type: Petrol

Ignition: DC – CDI

Brakes

Brakes Front: Dual Hydraulic Disc

Brakes Rear: Hydraulic Disc

Suspension

Front Suspension: Independent Double Wishbone, 7.1 in w/ 5-way Pre-load Adjustment

A-Arm Skid Plate (Front): Yes

Suspension - Front Travel (mm / in.): 180.3 / 7.1

Front Adjustable Fork Pre-Load: Yes

Front Adjustable Rebound Damping: No

Suspension Rear: Swing Arm, 7.1 in w/5-way Pre-load Adjustment

Suspension Rear - Material: Steel

Rear Travel (mm / in.): 180.3 / 7.1

Rear Adjustable Rebound Damping: No

Rear Adjustable Shock Spring Pre-Load: Yes

Number of Rear Shock Absorbers: 1

Air Adjustable: No

Dimensions and Weight

Length (mm / in.): 1979 / 77.9

Width (mm / in.): 1059 / 41.7

Height (mm / in.): 1095 / 43.1

Ground Clearance (mm / in.): 221 / 8.7

Wheelbase (mm / in.): 1231.9 / 48.5

Dry Weight (Kg / Lbs.): 234.1 / 516

Transmission (Gearbox) and Final Drive

Transmission: Yamaha Ultramatic V-Belt / F,N,R

Final Drive: Yamaha On-Command push button 2WD, 4WD ; Shaft

Drive line Modes: 2

Primary Drive Engine / Transmission: Belt

Primary Drive - Front Wheels: Shaft

Driveline Make: On-Command

Hi / Low Range: No

Reverse: Yes

Tires and Rims

Tires Front: AT23 x 8-12

Front Tire Diameter (in): 23

Front Tire Width (in): 8

Front Rim Diameter (in): 12

Tires Rear: AT23 x 10-12

Rear Tire Diameter (in): 23

Rear Tire Width (in): 10

Rear Rim Diameter (in): 12

Rim Material: Aluminum

Rear Solid Axle: Yes

Fuel

Fuel Tank Capacity (l / gal.): 14.4 / 3.8

Racks and Payload

Rear Rack: Standard

Storage

Underseat Storage: Standard

Seats

Seat Height (mm / in.): 840.7 / 33.1

Number Of Seats: 1

Seat Location: Driver

Seat Material: Vinyl

Seat Type: One-Piece

Seat Adjustable: No

Towing

Towing Capacity (Kg / Lbs.): 499.9 / 1102

Instrumentation

Instumentation: Digital Speedometer and Odometer

Digital Instrumentation: Standard

Trip Odometer: Standard

Fuel Level Warning Type: Gauge

Speedometer: Standard

Lighting

Lighting: Dual 30W Krypton Multi-reflector Headlights & 21/5W Brake light

Headlights: Standard

Halogen Headlights: Standard

Colours

Colors: Team Yamaha Blue, White/Silver

Metallic: No

Exterior - Safety and Design

Bash Plate (Front): Yes

Body Material: Plastic

Brush Guard: Yes

CV Boot Cover: Yes

Floor Board Location: Driver

Foot Peg Location: Driver

Folding Foot Pegs: No

Frame: Steel

Front Bumper: Standard

Front Fender: Standard

Front Stabilizer Bar: No

Full Length Skid Plate: Yes

Grab Rail Or Strap: Standard

Hand Grips: Standard

Radiator Guard: No

Rear Bumper: Standard

Rear Fender: Standard

Rear Stabilizer Bar: No

Steering

Steering Type: Manual

Turning Circle: 9.8

Manufacturer and Warranty

Manufacturer Country: Japan

Recommend Minimum Age: 16

Parent Company: Yamaha

Warranty Info: 6 Month (Limited Factory Warranty)

2006 Yamaha Wolverine 450 4x4 ATV Specs South Africa

Yamaha Wolverine 450 4x4 2006
