2006 Yamaha Wolverine 350 ATV Specs South Africa

2006 Yamaha Wolverine 350 - Racing Quad Bikes. Full specs, photos & comparison.

2006 Yamaha Wolverine 350 ATV quad bike specs

Yamaha Wolverine 350 2006

Make

Yamaha

Model

Wolverine

Year

2006

Type

Racing Quad Bikes

Compare This Quad

Add to side-by-side comparison (up to 4 quads)

View Comparison

Engine Spec

Engine Detail: 348 cc, 4-stroke, SOHC, air-cooled, single

Engine Capacity (cc / Ci ): 348 cc / 21.2

Engine Valves: SOHC

Valve Configuration: 2-valves

Total Valves: 2

Engine Type: 4-stroke

Engine Cooling: air-cooled

Engine Cylinders: single-cylinder

Engine Braking: Standard

Displacement To Weight CC: 0.73

Bore Stroke(mm): 83 mm x 64.5 mm

Bore Stroke(in): 3.27in. x 2.54 in.

Compression Ratio: 9.2:1

Fuel System: Mikuni BST34

Fuel System Brand: Mikuni

Carburetor Size MM: 33

Carborator Count: 1

Fuel Type: Petrol

Ignition: CDI Electric/recoil

Speed Governor: No

Brakes

Brakes Front: Dual hydraulic discs

Brakes Rear: Single hydraulic discs

Suspension

Front Suspension: Double wishbone

A-Arm Skid Plate (Front): Yes

Suspension - Front Travel (mm / in.): 160 / 6.3

Front Adjustable Fork Pre-Load: Yes

Front Adjustable Rebound Damping: No

Suspension Rear: Monocross

Suspension Rear - Material: Steel

Rear Travel (mm / in.): 180.3 / 7.1

Rear Adjustable Rebound Damping: No

Rear Adjustable Shock Spring Pre-Load: Yes

Number of Rear Shock Absorbers: 1

Air Adjustable: No

Dimensions and Weight

Length (mm / in.): 1870 / 73.6

Width (mm / in.): 1075 / 42

Height (mm / in.): 1150 / 45

Ground Clearance (mm / in.): 221 / 8.7

Wheelbase (mm / in.): 1231.9 / 48.5

Dry Weight (Kg / Lbs.): 216.8 / 478

Transmission (Gearbox) and Final Drive

Transmission: 5-forward, 1 reverse (semi automatic)

Transmission Make: UltraMatic

Final Drive: Shaft

Drive line Modes: 1

Primary Drive Engine / Transmission: Belt

Primary Drive - Rear Wheels: Shaft

Hi / Low Range: No

Reverse: Yes

Tires and Rims

Tire Make: Maxxis

Tires Front: 23 x 8-12

Front Tire Diameter (in): 23

Front Tire Width (in): 8

Front Rim Diameter (in): 12

Tires Rear: 23 x 10-12

Rear Tire Diameter (in): 23

Rear Tire Width (in): 10

Rear Rim Diameter (in): 12

Rim Material: Steel

Rear Solid Axle: Yes

Fuel

Fuel Tank Capacity (l / gal.): 13 / 3.4

Storage

Storage Capacity (Kg / Lbs.): 59.9 / 132

Underseat Storage: Standard

Seats

Seat Height (mm / in.): 789.9 / 31.1

Number Of Seats: 1

Seat Location: Driver

Seat Material: Vinyl

Seat Type: One-Piece

Seat Adjustable: No

Towing

Towing Capacity (Kg / Lbs.): 499.9 / 1102

Lighting

Lighting: Halogen

Headlights: Standard

Halogen Headlights: Standard

Colours

Colors: Blue

Metallic: No

Exterior - Safety and Design

Bash Plate (Front): Yes

Body Material: Plastic

Exterior Covers: Standard

Exterior Guards: Standard

Floor Board Location: Driver

Foot Pegs: Standard

Folding Foot Pegs: No

Frame: Steel

Front Bumper: Standard

Front Fender: Standard

Front Stabilizer Bar: No

Hand Grips: Standard

Rear Fender: Standard

Rear Stabilizer Bar: No

Steering

Steering Type: Manual

Turning Circle: 9.8

Performance

Torque (Nm): 2.64 kg-m @ 6000 rpm

Manufacturer and Warranty

Manufacturer Country: Japan

Recommend Minimum Age: 16

Parent Company: Yamaha
